Describe a payment as a set of legs, and the kernel checks the whole set before any balance moves. It matches debits against credits per asset, computes a transfer-set root, and journals every account it touches. If one leg fails, the journal rolls the set back and you get the failing leg index with an error code. Modules request money through the same primitive, so a handler cannot write a balance on its own.

What it does

LayerX has a single money primitive: a transfer set made of legs, where each leg is a from account, a to account, an asset, an amount, a reason code and a supply mode. The kernel checks the whole set, computes a Merkle root over it, journals every touched account, then applies the legs in order. If any leg fails, the journal rolls the set back completely and the caller gets the failing leg index and the error code. Modules request money movement through this primitive; a module handler that tries to write a balance itself is refused.

Key capabilities

• Up to 256 legs per set, applied in order, rolled back together on any failure.
• Per-asset conservation check: debits must equal credits before any balance moves.
• Merkle transfer-set root computed over all legs before the first balance change.
• Journal snapshots balance, asset, and next sequence per touched account for exact rollback.
• Supply modes CONSERVED, CREDIT_ONLY and DEBIT_ONLY cover transfers, mints and burns.
• Failure reports the original leg index and error code rather than a generic reject.

Differentiators

Value movement has exactly one code path: the kernel refuses a set if it carries a client-supplied balance (CLIENT_SUPPLIED_BALANCE, -410), refuses a module that already applied a transfer within the same activity (BALANCE_BYPASS, -408), and module handlers that would write a balance directly return LXP_ERR_MODULE_MAY_NOT_WRITE_BALANCE (-722). Rollback also restores the authority scope that a debit already charged, so a failed set does not consume allowance.

Outcomes

• Pay a provider, a fee and an escrow in one settlement
• Never reconcile a half-applied payment, because a failed set leaves no trace
• Read the failing leg index and error code instead of a generic reject

Technical notes

• Limits: LXP_MAX_TRANSFER_SET_LEGS = 256; the journal holds up to 512 account snapshots; the kernel passes at most LXP_KERNEL_MAX_TRANSFER_ASSETS = 64 asset states into a set.
• Amounts are unsigned 128-bit. Conservation is accumulated in 256 bits per asset; a mismatch returns CONSERVATION (-405).
• Zero-amount legs are dropped before the set is applied; a set with nothing left returns ZERO_AMOUNT (-401). Dropped legs do not shift the reported failure index.
• Each leg is hashed from a fixed 115-byte encoding: supply mode, from id, to id, asset id, amount big-endian, reason big-endian. The tree pairs a lone node with itself.
• Per-leg preconditions: asset registered and not paused, asset match on both accounts, neither account frozen, custody and authority checks, allowance, sequence, idempotency and expiry. Ledger error codes run -400 to -418.
• Reason codes are a fixed list of 23, from LXP_REASON_PAYMENT (1) to LXP_REASON_STORAGE_OCCUPANCY (23).
• The actor's sequence advances once per set, not once per leg.
• The transfer-set root appears in the receipt, so a client can check which legs a receipt covers.

// npm install layerx-sdk   (Node.js 22+)
import { verifyReceipt } from "layerx-sdk";

const verified = await verifyReceipt(canonicalReceipt, authorized);
const setRoot = verified.receipt.transferSetRoot;

for (const effect of verified.receipt.effects) {
  if (effect.monetary) {
    console.log(effect.moduleId, effect.transferSetRoot);
  }
}
